The Octek range of motherboards have won a large number of awards and are consistently listed in the top 5 of many industry standard performance lists. ZCM Services supplies the entire range of Octek motherboards, starting at the Rhino 12+, right up to the Rhino IIBX.

Octek were the first manufacturer to introduce such advances as synchronous cache, on board switch - mode processor voltage regulators, and option for full motherboard health monitoring (on Rhino IILX and Rhino IIBX)

Take a tour of the Octek motherboard manufacturing facilities.


Octek Rhino MVP3 MotherboardThe Rhino MVP3 is an 'AT' formfit motherboard for 'Socket 7' processors. It is based on the Apollo VIA MVP3 chipset. It has 512k SYNC Cache, support for EDO and SDRAM DIMM, and accepts up to 333MHz IBM/Cyrix or AMD processors.

Other features:


Octek Rhino IILX AT MotherboardFor the high end user Octek also provide a range AT and ATX footprint motherboards using single or DUAL Pentium II processors. These units are the ideal basis for a high - end server or full motion video editing suite.

The Rhino IILX AT is based on the Intel 440LX chipset. It provides the ideal foundation for a Pentium II or Celeron (242CSC) based system. All features provided by the LX chipset are exploited, including AGP (Accelerated Graphics Port).


Octek Rhino IIBX S-ATX MotherboardThe latest entrant in the Octek Pentium II/III range is the Rhino IIBX ATX. This ATX footprint motherboard utilises the Intel 440BX chipset, which boasts a 100MHz external bus speed and support for processor core speeds of up to 500MHz.

The expansion features:

The Rhino IIBX is also available in a small footprint version as the Rhino IIBX SATX. To reduce the size to conform to SATX standard the number of connection slots is reduced to 2 ISA and 3 PCI. All other features are unchanged.


All Octek motherboards have a 2 Year warranty. Any of the Octek range of motherboards can also be supplied in a complete system, with your choice of peripherals and features. See the ZCM Services system page for details.

Price Guide - Octek / Intel Motherboards
CodeItem DescriptionRetail PriceWarranty
OCTRHMVP3Rhino MVP3 AT Pentium PCI Motherboard, Socket 7, Supports up to 333MHz processor, Selectable Processor/RAM Bus: 50/60/66/75/83/95/100 MHz, 3 x 168 pin DIMM 100MHz SDRAM socket, VIA Apollo MVP3 Chipset, 512kB Cache, 4 x 32 bit PCI slots, 3 x ISA slots, AGP Video Port, Dual USB Port, on-board dual EIDE / Floppy disk / 2 x 16550 serial / parallel ports, Dual AT/ATX Power Connectors. $146.002 Years
OCTRHIILXRhino II LX-AT Pentium II PCI Motherboard, 242CSC, Supports up to 333MHz processor, 2 x 168 pin DIMM SDRAM socket, Intel LX Chipset, 3 x 32 bit PCI slots, 3 x ISA slots, AGP Video Port, Dual USB Port, on-board dual EIDE / Floppy disk / 2 x 16550 serial / parallel ports, Dual AT/ATX Power Connectors. $141.002 Years
OCTRHIILX370Rhino II LX-AT Pentium II PCI Motherboard - as above socket 370 for Celeron processors to 450MHz.$135.002 Years
OCTRHIIZXRhino II ZX-AT Pentium II / III PCI Motherboard, Socket 370 PPGA, Supports up to 450MHz Celeron processor, 100MHz Processor/RAM Bus, 2 x 168 pin DIMM 100MHz SDRAM socket, Intel ZX Chipset, 4 x 32 bit PCI slots, 3 x ISA slots, AGP Video Port, Dual USB Port, on-board SB16 sound, dual EIDE / Floppy disk / 2 x 16550 serial / parallel ports.$172.002 Years
OCTRHIIBXRhino II BX-AT Pentium II / III PCI Motherboard, 242CSC, Supports up to 450MHz processor, 100MHz Processor/RAM Bus, 3 x 168 pin DIMM 100MHz SDRAM socket, Intel BX Chipset, 4 x 32 bit PCI slots, 3 x ISA slots, AGP Video Port, Dual USB Port, on-board dual EIDE / Floppy disk / 2 x 16550 serial / parallel ports.$179.002 Years
OCTRHIIBXeRhino II BX-ATXe Pentium II / III PCI Motherboard, 242CSC, Supports up to 450MHz processor, 100MHz Processor/RAM Bus, 3 x 168 pin DIMM 100MHz SDRAM socket, Intel BX Chipset, 4 x 32 bit PCI slots, 3 x ISA slots, AGP Video Port, Dual USB Port, on-board dual EIDE / Floppy disk / 2 x 16550 serial / parallel ports.$183.002 Years
INTT440BXIntel T440 ATX Pentium II / III Integrated Server Board, 242CSC, Supports up to 450MHz processor, 3 x 168 pin DIMM 100MHz SDRAM, Intel 440BX chipset, 3 x 32 bit PCI slots, 2 x ISA slots, (Integrated Peripherals: Cirrus Logic CL5446 Graphics Adapter, Intel Ether Express Pro 10/100 Network Adapter, Adaptec Ultra Wide SCSI Adapter) on-board dual Mode 4 EIDE / Floppy disk / 2 x 16550 serial / parallel ports. $769.002 Years
INTL440BXIntel L440GX+ ATX DUAL Pentium II / III Integrated Server Board, Dual 242CSC, Supports up to 550MHz processor, 100MHz Processor/RAM Bus, 4 x 168 pin DIMM 100MHz SDRAM with ECC, Intel 440GX chipset, 3 x 32 bit PCI slots, 2 x ISA slots, (Integrated Peripherals: Cirrus Logic GD5480 Graphics Adapter, Intel Ether Express Pro 10/100 Network Adapter, Adaptec Dual Channel Ultra Wide SCSI Adapter) on-board dual Mode 4 EIDE / Floppy disk / 2 x 16550 serial / parallel ports. $1250.002 Years
370RISERRiser Card to Adapt 242CSC Processor Slot to Socket 370 (PPGA) Processor$24.002 Years
